Home >> Pontiac >> 2002 >> Firebird Formula, Automatic >> Repair and Diagnosis >> Electrical >> Body Electrical >> OEM Connector End Views >> Connector End Views >> Stop Lamp Switch Connector End View C2

Stop Lamp Switch Connector End View C2

Fig 1: Stop Lamp Switch Connector End View C2

G01767418

Courtesy of GENERAL MOTORS CORP.
