Removal Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the left windshield garnish molding. Refer to GARNISH MOLDING REPLACEMENT - WINDSHIELD PILLAR in INTERIOR TRIM .
  2. Remove the left center pillar assist handle. Refer to ASSIST HANDLE REPLACEMENT - REAR in INTERIOR TRIM .
  3. Remove the left center pillar garnish molding. Refer to GARNISH MOLDING REPLACEMENT - CENTER PILLAR in INTERIOR TRIM .
  4. Remove the left sunshade. Refer to SUNSHADE REPLACEMENT in INTERIOR TRIM .
  5. Gently pull down the headliner.
    Fig 1: Disconnecting Electrical Connector From Inside Air Temperature Sensor
    G01454863Courtesy of GENERAL MOTORS CORP.
  6. Disconnect the electrical connector from the inside air temperature sensor.
  7. Partially remove the inside air temperature sensor from the headliner.
  8. Remove the sensor grille from the inside air temperature sensor.
  9. Remove the inside air temperature sensor from the headliner.
    Fig 2: Removing Inside Air Temperature Sensor From Headliner
    G01454864Courtesy of GENERAL MOTORS CORP.
