Engine Mount Strut and Engine Lift Bracket Installation

  1. Install the engine mount strut and lift bracket.
  2. Install the engine mount strut and lift bracket bolts.

    Tighten

    Tighten the engine mount strut and lift bracket bolts to 70 N.m (52 ft. lbs).

    Fig 1: Installing Engine Mount Strut And Lift Bracket
    G01745679Courtesy of GENERAL MOTORS CORP.
