Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front door trim plate (1). Refer to Door Trim Plate Replacement (Manual Windows)  or Door Trim Plate Replacement (Power Windows)  or Door Trim Plate Replacement (Side/Rear Door)  .
  2. Remove the electrical connector (2) from the power mirror switch (9).
  3. Release the clip that retains the escutcheon to the front door trim plate (1).
  4. Remove the escutcheon and the power mirror switch (9) from the front door trim plate (1).
  5. Release the retaining tabs on the power mirror switch (9) from the escutcheon.
  6. Remove the power mirror switch (9) from the escutcheon.
Fig 1: Removing Power Mirror Switch
G01736952Courtesy of GENERAL MOTORS CORP.
