Float Drop

Hold bowl cover upright with float hanging down at bottom of travel. Distance from lower face of cover gasket to bottom of float at free end should be as indicated in specification table. To adjust, bend float tang on rear of float arm.

Fig 1: FLOAT DROP ADJUSTMENT

Courtesy of GENERAL MOTORS COMPANY
