Test K: Doors Fail To Unlock From One Switch: Notes

For doors fail to unlock from one switch diagnostic procedures, see Figure. For component locations, see COMPONENT LOCATIONS . For connector terminal identification, see CONNECTOR IDENTIFICATION . For circuit and wiring diagrams, see WIRING DIAGRAMS .
