Rear Suspension: Description

Rear suspension uses an independent, MacPherson strut design. See Fig 1 . Each side consists of a strut assembly, 2 parallel control arms, tension strut, knuckle and strut-mounted stabilizer bar.

Fig 1: Identifying Rear Suspension Components

Courtesy of CHRYSLER CORP.
