Entering DRB-II Main Menu

  1. Ensure ignition is off. Attach DRB-II to Chrysler Collision Detection (CCD) BUS data link connector. Data link connector is located behind fuse access cover on lower section of dash panel, left of steering column. See Figure and Figure . Turn ignition switch to RUN position.
  2. All DRB-II character positions will glow and copyright information will appear on screen for a few seconds. DRB-II main menu will appear after a few seconds. If DRB-II screen is blank, proceed to TEST 2A  under SELF-DIAGNOSTICS. If DRB-II displays NO RESPONSE message, go to TEST 3A  .
