Steering Column: Inspection
- Check for separation of the 2 break-away capsules. If capsules have moved more than 1/16" (1.6 mm), some column collapse may have occurred. Check for damaged steering shaft components.
- Inspect jacket section of column for looseness, bends, collapsed mesh or bellows section.
- On column shift models, check operation of shift lever. If lever can be moved to "PARK" position without raising lever, upper shift tube plastic bearing is broken.
- Inspect intermediate and steering column shafts for sheared plastic pins. If the shafts rattle when tapped lightly from side pins are sheared. Replace any collapsed or damaged parts.
