Shift Linkage: Conquest

Place shift lever in "N" position. Transmission selector lever should also be in Neutral. If not, loosen lock nuts on end of cross shaft below shift lever assembly. Adjust selector rod and tighten lock nuts. See Fig 1.

Fig 1: Adjusting Conquest Shift Linkage

Courtesy of CHRYSLER MOTORS.

Fig 2: Adjusting Raider Neutral Safety Switch

Courtesy of CHRYSLER MOTORS.

Fig 3: Adjusting Raider Shift Linkage

Courtesy of CHRYSLER MOTORS.

Fig 4: Adjusting Selector Cam on Shift Lever

Courtesy of CHRYSLER MOTORS.
