Hall Effect Pick-up Assembly

This device is located in the distributor to supply a basic timing signal to the computer. The computer determines engine speed (RPM) based on this signal. See Figure .

Fig 1: Location of Hall Effect Pick-Up Assembly in Distributor
G9097
