Mechanical Switch Reset

Locate switch on front of dash in engine compartment, in line with speedometer cable. Slide rubber boot up and turn small screw to reset switch. Replace boot.

Fig 1: Oxygen Sensor Lamp Mileage Counter (Mechanical Switch Shown)
G09339795Courtesy of CHRYSLER GROUP, LLC
