Power Door Locks: Description
All door locks are operated by either of the front door locking buttons. The locks on the right front and both rear doors can be manually operated with the door lock buttons. The drivers door can be unlocked manually from inside, but must be locked electrically. On Chrysler New Yorker Brougham, the left front door can be locked manually from inside door locking console lever. The tailgate door, locks electrically when the ignition is turned "ON". It may be unlocked manually when ignition is "ON" by pressing and holding spring loaded unlock switch while opening tailgate. All locks are operated by push-pull double action solenoids, attached by connecting rods to door lock actuating levers in each door. A single pole double throw switch is mounted on each front door and a console mounted toggle switch is used to control system. Trunk lid lock consists of a push button switch and a solenoid, which is energized only when switch is depressed.
