Installation Procedure

    Fig 1: View Of Armrest Bracket
    GM797853Courtesy of GENERAL MOTORS CORP.
  1. Position the door handle pull bracket to the door.
    2. NOTE: Refer to Fastener Notice in Cautions and Notices.
  2. Install the door handle pull bracket screws.

    Tighten:  Tighten the screws to 10 N.m (89 lb in).

  3. Install the rear door trim panel. Refer to Trim Panel Replacement - Side Rear Door (Oldsmobile) Trim Panel Replacement - Side Rear Door (Pontiac)  or Trim Panel Replacement - Side Rear Door (Oldsmobile) Trim Panel Replacement - Side Rear Door (Pontiac) .
