Cellular Communication Connector End Views

Fig 1: Identifying Cellular Communication Connector End View
G01507189Courtesy of GENERAL MOTORS CORP.
Fig 2: Identifying Vehicle Communication Integration Module Connector End View
G01507190Courtesy of GENERAL MOTORS CORP.
