Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the stop lamp switch (2) to the brake pedal bracket.
  2. Connect the electrical connector to the stop lamp switch.
  3. Install the left side of the I/P insulator.
  4. Adjust the stop lamp switch. Refer to STOP LAMP SWITCH ADJUSTMENT  .
    Fig 1: Installing Stop Lamp Switch To Brake Pedal Bracket
    G01503203Courtesy of GENERAL MOTORS CORP.
