Torque Specifications
WARNING: This page is about a different car, the 1998 Oldsmobile Aurora and 1998 Buick Riviera. However, it is still accessible from the selected car via links, so may be relevant.
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|---|
| Intermediate Shaft Pinch Bolt | 35 (47) |
| Steering Column Support Nuts | 20 (27) |
| Steering Wheel Nut | 30 (41) |
| INCH Lbs. (N.m) | |
| Ignition Switch Screws | 13 (1.5) |
| Inflator Module Nut/Screw Driver's Side | 27 (3) |
| Interlock Solenoid Screws (Column Shift) | 18 (2) |
| Intermediate Shaft Seal Screw | 21 (2.4) |
| Linear Shift Base Adapter | 89 (10) |
| Lock Bolt Support Bracket Screws | 22 (2.5) |
| Pivot & Pulse Switch Screws (Floor Shift) | 22 (2.5) |
| Steering Column Support Screws | 71 (8) |
| Steering Column Wiring Harness Connector | 71 (8) |
| Tilt Lever Knob Screw | 31 (3.5) |
| Turn Signal & Multifunction Switch Screws | 44 (5) |
| Upper & Lower Cover Screws | 44 (5) |
