Diagnostic Aids

This code will not set due to vacuum leaks or vacuum supply problem. Ensure driver has not exceeded set speed by 20 MPH.

Fig 1: Code 63 Schematic (4.0L) Cruise Control Set Speed Vehicle Speed Mismatch

Fig 2: Code 63 Diagnostic Flow Chart (4.0L) Cruise Control Set Speed Vehicle Speed Mismatch
