Window Mechanism Binds
Ease of window operation and window stability depend on belt trim support retainer adjustment. See Fig 1 . Belt trim support retainers should contact glass throughout full up/down cycle of window. Slight variations in glass contour may cause retainer to lose contact with glass halfway through the cycle. This is okay, provided the result is not loose glass. Contact should be enough to stabilize glass but not restrict ease of window operation.
