Component Location

View with A/C control removed

View with front door finisher (driver side) removed

View with rear door finisher LH removed

No.

Component parts

Function

Rear power window motor RH

Refer to Component Description .

Rear power window switch RH

Refer to Component Description .

Front power window motor (passenger side)

Refer to Component Description .

Front power window switch (passenger side)

Refer to Component Description .

BCM

• Controls power window relay
• Refer to Component Location for detailed installation location

Power window main switch

Refer to Component Description .

Rear power window switch LH

Refer to Component Description .

Power window relay

Supplies power supply to power window switch

Front power window motor (driver side)

Refer to Component Description .

Rear power window motor LH

Refer to Component Description .
