Exploded View

Fig 1: Front Lower Link With Torque Specification
GNSALEIA0100Z-100Courtesy of NISSAN NORTH AMERICA, INC.

1.

Rear stabilizer

2.

Stabilizer connecting rod

3.

Rear suspension member

4.

Front lower link

5.

Rear suspension arm

6.

Rear knuckle

7.

Rear lower link

8.

Spring lower seat

9.

Coil spring

10.

Spring upper seat

SYMBOL

Front
