Component Parts Location
WARNING: This page is about a different variant/trim than selected.
|
1. |
Combination meter |
2. |
ABS actuator and electric unit (control unit) |
3. |
Transmission range switch |
|
4. |
Input speed sensor |
5. |
Control valve |
6. |
CVT unit connector |
|
7. |
Primary speed sensor |
8. |
Output speed sensor |
9. |
BCM |
|
10. |
ECO mode switch |
11. |
SPORT mode switch |
12. |
Manual mode switch |
|
13. |
ECM |
14. |
TCM |
15. |
G sensor |
|
A. |
Engine compartment, passenger cowl area |
B. |
Left side of engine assembly |
C. |
Left side of dash area |
|
D. |
Instrument panel, LH |
E. |
Shift selector area |
F. |
Engine room, left front |
|
G. |
Engine compartment, left rear |
H. |
Under driver seat |
||
|
|
: Vehicle front |
NOTE:
- The following components are included in control valve assembly.
- CVT fluid temperature sensor
- Primary pressure sensor
- Secondary pressure sensor
- Line pressure solenoid valve
- Primary pressure solenoid valve
- Secondary pressure solenoid valve
- Torque converter clutch solenoid valve
- Select solenoid valve
