Exploded View
WARNING: This page is about a different variant/trim than selected.
|
1. |
Oil gallery cover |
2. |
Oil gallery cover gasket |
3. |
O-ring |
|
4. |
Oil pan (upper) |
5. |
Oil pump drive chain tensioner |
6. |
Oil pump drive chain |
|
7. |
Crankshaft sprocket |
8. |
O-ring |
9. |
Oil pump sprocket |
|
10. |
Oil pump |
11. |
Oil pan drain plug |
12. |
Drain plug washer |
|
13. |
Oil pan (lower) |
14. |
O-ring |
15. |
Oil level gauge |
|
16. |
Oil level gauge guide |
17. |
Oil filter |
18. |
Oil filter stud |
|
19. |
O-rings |
20. |
O-rings |
21. |
Engine oil pressure control solenoid valve |
|
22. |
Crankshaft position sensor |
23. |
O-ring |
24. |
Gasket |
|
25. |
Plug |
26. |
Rear oil seal |
A. |
Refer to Removal and Installation . |
|
B. |
Refer to INSTALLATION |
C. |
Oil pan side |
D. |
Refer to Removal and Installation . |
|
E. |
Refer to Removal and Installation . |
