Engine Cooling System Schematic
WARNING: This page is about a different car, the 2016 Nissan Rogue. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of NISSAN NORTH AMERICA, INC.
| 1. |
Radiator |
2. |
Water inlet |
3. |
Reservoir tank |
| 4. |
Thermostat |
5. |
Thermostat housing |
6. |
Water pump |
| 7. |
Cylinder head |
8. |
Cylinder block |
9. |
Water outlet |
| 10. |
Heater |
11. |
Oil cooler |
12. |
Electric throttle control actuator |
| 13. |
CVT oil warmer |
A. |
Open |
B. |
Closed |
