Removal and Installation: Removal

  1. Remove the rear door armrest finisher. Refer to "REMOVAL AND INSTALLATION ".
  2. Release the pawls on each side to separate the switch finisher (1) from the rear power window switch (2) using a suitable tool (A).
    Fig 1: Removing Rear Door Armrest Finisher
    G09557884Courtesy of NISSAN NORTH AMERICA, INC.
