Versa SL, 4D Hatchback
>>
Repair and Diagnosis
>>
Engine Performance
>>
System
>>
Engine Control System - Introduction (Hatchback)
>>
Service Information
>>
Trouble Diagnosis
>>
Circuit Diagram
Circuit Diagram
Fig 1: Vacuum Control System Circuit Wiring Diagram (1 Of 2)
Courtesy of NISSAN NORTH AMERICA, INC.
Fig 2: Vacuum Control System Circuit Wiring Diagram (2 Of 2)
Courtesy of NISSAN NORTH AMERICA, INC.
