Engine Control System - Component Testing (CALIFORNIA)
>>
Removal And Installation
>>
EVAP Canister
>>
Exploded View
Exploded View
Fig 1: Exploded View Of EVAP Canister With Torque Specifications
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
