Home >> Nissan-Datsun >> 2009 >> Versa Base, Automatic >> Repair and Diagnosis >> Transmission >> Automatic Transmission >> Transmission Control Module >> Removal and Installation >> Components

Removal and Installation: Components

Fig 1: Transmission Control Module Replacement Components With Torque Specifications

G04813166

Courtesy of NISSAN MOTOR CO., U.S.A.
