Top Tether Strap Child Restraint
>>
Exploded View
Exploded View
Fig 1: Exploded View Of Top Tether Strap Child Restraint
Courtesy of NISSAN MOTOR CO., U.S.A.
Refer to "
COMPONENTS
" for symbols in the figure.
