Home >> Nissan-Datsun >> 2007 >> X-Trail LE >> Repair and Diagnosis >> Transmission >> Automatic Transmission >> A/T Control System >> Shift Mechanism >> Construction

Shift Mechanism: Construction

Fig 1: Shift Mechanism Construction

G06154021

Courtesy of NISSAN MOTOR CO., U.S.A.
