Control Valve Assembly and Accumulators: Installation

Installation is in the reverse order of removal.

• Set manual shaft in Neutral, then align manual plate with groove in manual valve.
• After installing control valve assembly, make sure that selector lever can be moved to all positions.
  Fig 1: Identifying Servo Release And N-D Accumulators

  Courtesy of NISSAN MOTOR CO., U.S.A.
