Removal and Installation of Optical Sensor: Removal

WARNING: This page is about a different car, the 2005 Nissan Armada. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove defrost grille. Refer to INSTRUMENT PANEL .
  2. Disconnect the connector.
  3. Turn the optical sensor counterclockwise to remove it from defroster grille.
    Fig 1: Identifying Optical Sensor
    G02441297Courtesy of NISSAN MOTOR CO., U.S.A.
