CAN Communication Line Check

  1. CHECK MONITOR DESCRIPTION
    1. Start display control unit self-diagnosis. Refer to "SELF-DIAGNOSIS MODE (DCU) ".
    2. Select "CAN DIAG SUPPORT MONITOR". Refer to "CAN DIAG SUPPORT MONITOR ".
      Fig 1: Item Content Normal Condition Description
      G02528250Courtesy of NISSAN MOTOR CO., U.S.A.
      Fig 2: Scan Tool Display - Can Diag Support Monitor
      G02528251Courtesy of NISSAN MOTOR CO., U.S.A.
    3. Record each item display description (OK/NG/UKNWN) displayed on the following CAN DIAG SUPPORT MONITOR Check Sheet.

      CAN DIAG SUPPORT MONITOR Check Sheet

      DIAGNOSIS ITEM

      Diagnosis item Screen display Diagnosis item Screen display
      CAN_COMM OK NG CAN_CIRC_5 OK UNKWN
      CAN_CIRC_1 OK UNKWN CAN_CIRC_6 OK UNKWN
      CAN_CIRC_2 OK UNKWN CAN_CIRC_7 OK UNKWN
      CAN_CIRC_3 OK UNKWN CAN_CIRC_8 OK UNKWN
      CAN_CIRC_4 OK UNKWN CAN_CIRC_9 OK UNKWN

      :After filling in CAN DIAG SUPPORT MONITOR Check Sheet, GO TO "CAN COMMUNICATION ".
