Combination Switch

WARNING: This page is about a different car, the 2003 Infiniti G35. However, it is still accessible from the selected car via links, so may be relevant.

Remove bolts of cluster lid A.

Fig 1: Locating Cluster Lid A Bolts
Courtesy of NISSAN MOTOR CO., U.S.A.
Remove pawl on upper and lower of combination switch.
Disconnect harness connector of wiper washer switch.
Use clothes to protect cluster lid A and combination switch from damage. Remove combination switch through gap between cluster lid A and steering wheel.
