DTC Confirmation Procedure: Notes
WARNING: This page is about a different car, the 2003 Infiniti G35. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
With CONSULT-II
- Start engine.
- Accelerate vehicle to maintain the following condition.
ACCELE POS: 1.5/8 - 2.0/8
Selector lever: "D" position
Gear position: 3rd --> 4th Gear (FR/B ON/OFF)
Driving location: Driving the vehicle uphill (increased engine load) will help maintain the driving conditions required for this test.
- Perform step " 2" again.
- Turn ignition switch OFF, then perform step " 1" to " 3" again.
- Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC P1759 is detected, Refer to "DIAGNOSTIC PROCEDURE ". If DTC P1757 is detected, go to "DIAGNOSTIC PROCEDURE ". If DTC P1841 is detected, go to "DIAGNOSTIC PROCEDURE ".
