Side Mudguard: Components

WARNING: This page is about a different car, the 2006 Scion tC. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Removing Screw And Wheel House Plate
G04224760Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
