Driver Side Knee Airbag Assembly: Installation

WARNING: This page is about a different car, the 2006 Scion tC. However, it is still accessible from the selected car via links, so may be relevant.

CAUTION: Be sure to read the precautionary notices concerning the SRS airbag system before servicing it (see AIRBAG SYSTEM ).

INSTALL DRIVER SIDE KNEE AIRBAG ASSEMBLY
1. Connect the connector.
  NOTE: When handling the airbag connector, take care not to damage the airbag wire harness.
2. Install the front passenger side knee airbag with the 3 bolts.
Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf)

Fig 1: Installing Front Passenger Side Knee Airbag With Bolts
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
PERFORM INITIALIZATION
1. Perform initialization (see INITIALIZATION ).
NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
CHECK SRS WARNING LIGHT
1. Check the SRS warning light (see DIAGNOSIS SYSTEM ).
