Home >> Nissan-Datsun >> 2004 >> Sentra SE-R >> Repair and Diagnosis >> Engine Mechanical >> Lubrication System >> Engine Lubrication - Qr25DE >> Oil Pump >> Disassembly and Assembly >> Notes

Disassembly and Assembly: Notes

Fig 1: Removing/Installing Oil Pump Assembly
G03510911Courtesy of NISSAN MOTOR CO., U.S.A.
CAUTION: Before installation, apply new engine oil to the parts as instructed in the figure.
