ASCD Steering Switch

  1. Disconnect ASCD steering switch.
  2. Check continuity between ASCD steering switch terminals 1 and 2 with pushing each switch.
    Fig 1: Switch Condition Resistance Table
    G02885897Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 2: Checking Continuity Between ASCD Steering Switch Terminals 1 And 2
    G02885898Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 3: Switch Condition Resistance Table
    G02885899Courtesy of NISSAN MOTOR CO., U.S.A.
