Nissan-Datsun
>>
2004
>>
Altima Base, Automatic
>>
Repair and Diagnosis
>>
Transmission
>>
Automatic Trans
>>
Automatic Transaxle
>>
Overall System
>>
Shift Mechanism
>>
Construction
Shift Mechanism: Construction
Fig 1: Shift Mechanism Construction
Courtesy of NISSAN MOTOR CO., U.S.A.
Courtesy of NISSAN MOTOR CO., U.S.A.
