Rear Wheel Alignment: Camber

WARNING: This page is about a different car, the 2003 Nissan Altima and 2002 Nissan Altima. However, it is still accessible from the selected car via links, so may be relevant.

Measure camber of both right and left wheels with a suitable alignment gauge and adjust in accordance with the following procedures.
1. Camber : Refer to SPECIFICATIONS .
Fig 1: Checking Camber
Courtesy of NISSAN MOTOR CO., U.S.A.
If camber is not within specification, adjust by turning the adjusting bolts in the same direction.

Turn the adjusting bolts in the same direction to calibrate.
NOTE: Camber changes about 5° with each graduation of the adjusting bolt.

Fig 2: Adjusting Camber (1 Of 2)
Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 3: Adjusting Camber (2 Of 2)
Courtesy of NISSAN MOTOR CO., U.S.A.
Tighten to the specified torque. Refer to TORQUE SPECIFICATIONS .
