A/T Fluid Temperature Sensor 1

WARNING: This page is about a different car, the 2006 Nissan Titan. However, it is still accessible from the selected car via links, so may be relevant.

Remove control valve with TCM. Refer to "CONTROL VALVE WITH TCM AND A/T FLUID TEMPERATURE SENSOR 2 ".

Check resistance between terminals.

Fig 1: Checking Resistance Between A/T Fluid Temperature Sensor 1 Connector Terminals

Courtesy of NISSAN MOTOR CO., U.S.A.

TERMINAL RESISTANCE SPECIFICATION

Name	Terminal	Temperature °C (°F)	Resistance (Approx.) (kΩ)
A/T fluid temperature sensor 1	6 - 7	0 (32)	15
		20 (68)	6.5
		80 (176)	0.9

If NG, replace the control valve with TCM. Refer to "CONTROL VALVE WITH TCM AND A/T FLUID TEMPERATURE SENSOR 2 ".
