Fluid Leakage And Fluid Level

WARNING: This page is about a different car, the 2005 Nissan Frontier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Make sure that fluid is not leaking from the transfer assembly or around it.
  2. Check fluid level from the filler plug hole as shown.
    CAUTION: Do not start engine while checking fluid level.
  3. Install the filler plug with a new gasket to the transfer. Tighten to the specified torque. Refer to "COMPONENTS ".
    CAUTION: Do not reuse gasket.
    Fig 1: Installing Filler Plug With Gasket To Transfer
    G03595274Courtesy of NISSAN MOTOR CO., U.S.A.
