Removal and Installation of Trunk Lid Lock Assembly: Removal

WARNING: This page is about a different car, the 2005 Nissan 350Z. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the trunk lid weatherstrip. Refer to "REMOVAL AND INSTALLATION OF TRUNK LID WEATHERSTRIP ".
  2. Remove trunk lid release lever. Refer to "REMOVAL AND INSTALLATION (FOR ROADSTAR MODELS) ".
  3. Remove the trunk lid finisher. Refer to "TRUNK ROOM TRIM & TRUNK LID FINISHER ".
  4. Disconnect the release lever cable and trunk lid opener cable from the clip.
  5. After removing the harness connector, remove the mounting bolts, and remove the trunk lid lock.
    Fig 1: Disconnecting Release Lever Cable & Trunk Lid Opener Cable From Clip With Torque Specifications
    G02402462Courtesy of NISSAN MOTOR CO., U.S.A.
