Section 2004 (Manual Air Conditioner)
>>
Refrigeration System
>>
Component Layout
>>
Refrigeration System
Refrigeration System
WARNING:
This page is about a different car, the 2006 Nissan Titan. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Identifying Refrigeration System Components
