Direct Clutch: Assembly

WARNING: This page is about a different car, the 2005 Nissan Frontier. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install drive plates, driven plates and retaining plate in direct clutch drum.
    CAUTION: Take care with order of plates.
  2. Install snap ring in direct clutch drum using suitable tool.
    Fig 1: Installing Snap Ring In Direct Clutch Drum
    G03595167Courtesy of NISSAN MOTOR CO., U.S.A.
