Removal and Installation for Tweeter: Removal

WARNING: This page is about a different car, the 2005 Infiniti FX45 and 2005 Infiniti FX35. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove rear pillar upper garnish assembly. Refer to "REMOVAL AND INSTALLATION ".
  2. Remove screws (4), and disconnect connector.
  3. Remove tweeter.
    Fig 1: Disconnecting Connector
    G02365455Courtesy of NISSAN MOTOR CO., U.S.A.
