TCM Terminals and Reference Value: Preparation

WARNING: This page is about a different variant/trim than selected.

Measure voltage between each terminal and terminal 25 or 48 by following TCM INSPECTION TABLE.

Fig 1: Measuring Voltage Between Terminal 25 Or 28
Courtesy of NISSAN MOTOR CO., U.S.A.
