Illumination Control Switch

WARNING: This page is about a different car, the 2006 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove lower driver instrument panel. Refer to "REMOVAL ".
  2. Carefully lift tabs and pull illumination control switch out of lower driver instrument panel.

Installation is in the reverse order of removal.

Fig 1: Identifying Illumination Control Switch
G04200991Courtesy of NISSAN MOTOR CO., U.S.A.
