Exploded View

Fig 1: Exploded View Of Transverse Link With Torque Specifications

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

TORQUE SPECIFICATIONS

(1)	Front suspension member
(2)	Bush
(3)	Transverse link
	: Vehicle front
	: N.m (kg-m, ft-lb)
	: Always replace after every disassembly .
